Automatic Bottle Filling Honey Jars Packing Machine Peanut Butter Production Line

- IN STOCK
Voltage 220V/380V(Customizable)
Driven type Electric
Warranty 1 Year
Key selling points Multifunctional, High-Accuracy
Video outgoing-inspection Provided
place of origin Guangdong,China
After-sales Service Provided Video Technical Support,Field
installation, commissioning...
Function Weighing Filling Capping Labeling
Advantage Automatic Working
Feature High Precision Filling Level
Control PLC+ Touch Screen
Material Stainless Steel 304/316







Share Share on Facebook Share to Instagram Story

Dession liquid bottle filling line can automatically arrange bottles,fill liquid, cap bottle and lable bottle, it helps to save production process and improve working efficiency.

We can offer custom service for different kinds of materials,make these machines can match your material better.
It is widely used in food,beverage,cosmetics industries.
Model
DMS-6L
DMS-8L
DMS-10L
Filling range
100-1000ML
200-2000ML
300-3000ML
Filling speed(BPH)
1440-1800
1920-2400
2400-3000
Filling accuracy
±1%(it depends on filling volume and material)
Voltage
1KW/220V
1.2KW/220V
1.2KW/220V
Working pressure
0.6-0.8MPA
Tank volume
120L
200L
200L
Gas consumption
0.5-0.7MPA
0.5-0.8MPA
0.6-0.9MPA
Machine weight(KG)
450
500
550
Outline dimension(mm)
2000*1300*2100
2000*1300*2100
2000*1400*2200
Applicable bottle height（mm）
80-180(customized)
Applicable bottle diameter（mm）
60-100(customized)
